1st February 2017:

Streamline Solutions launches ELEMENTS v2.3.0



ENGYS is pleased to announce the release v2.3.0 of ELEMENTS, an open-source based CFD software suite for vehicle design applications produced by Streamline Solutions. The product combines two simulation environments in one package: a dedicated wizard type interface for modelling external vehicle aerodynamics, and a general purpose CFD interface for solving other vehicle design applications (e.g. UHMT, HVAC, in-cabin flows, aeroacoustics, soiling, etc).



ELEMENTS v2.3.0 incorporates several new features, improvements and bug fixes with respect to the previous release v2.2.0. The software also includes a new version of the open-source CFD simulation engine HELYX-Core (v2.2-2.5) developed by ENGYS based on the OpenFOAM libraries.



The External Aerodynamics GUI in ELEMENTS v2.3.0 is now fully configurable, enabling users to create their own custom-made CFD methodologies to model external aerodynamics using any given wind tunnel configuration and vehicle shape. Users have complete control over the meshing and solver settings to define any set of best simulation practices in accordance with their own in-house CFD procedures. All custom-made configurations can be easily deployed across the entire organisation to ensure that every external aerodynamics CFD model is defined and solved consistently in ELEMENTS using a common automated simulation approach.





In order to be ready for the planned regulations on alternative drag prediction methods found in the proposed Worldwide harmonized Light vehicles Test Procedure (WLTP), the default DES simulation best practices for external aerodynamics delivered with ELEMENTS are continuously improved and validated to provide highly accurate Δ(CD×Af) predictions within ±0.015m2 of wind tunnel measurements.



Other enhancements delivered with this new version of ELEMENTS include, but are not limited to:

  • Up-to-date ELEMENTS-Adjoint add-on solver module, featuring improved solver robustness, additional adjoint turbulence models and new optimisation objectives.
  • Improved interfaces for defining wheels and porous media in the External Aerodynamics GUI.
  • Added support for dynamic mesh solvers, including 6DoF and dynamic mesh refinement.
  • Improved features for data visualisation and post-processing, including automatic report generation in Windows systems.
  • Up-to-date documentation, all accessible via the Help menu in the GUI, including new comprehensive guides for HELYX-Core and ELEMENTS-Adjoint.

The latest installation files for both Linux and Windows are now available for download to all ELEMENTS customers from our Customer Portal at http://engys.com/clients.



For further information about ELEMENTS features and availability please visit the dedicated microsite at http://elements.streamline-cae.com or email elements@streamline-cae.com.



About Streamline Solutions:

Streamline Solutions LLC, a joint venture formed between ENGYS and Auto Research Center, was founded in the USA in early 2012 to serve the vehicle design software market, covering automotive, motorsports, commercial and military applications. The company develops and promote the software suite ELEMENTS, a CAE platform for CFD analysis and vehicle design optimisation powered by open-source technologies. Streamline Solutions combines ENGYS’ leading-edge software development and support, a long and reputable participation in the open-source software business, with ARC’s proven vehicle design expertise and world leading wind tunnel and experimental facilities for validation purposes.
